Fowler Baty R600 - XLS Horizontal Optical Comparator with Acu-rite DC 102 Readout - 14" Screen

Fowler Baty R600 - XLS Horizontal Optical Comparator with Acu-rite DC 102 Readout - 14" Screen - 53-900-960-5 The Fowler Baty R600 with its 24"/600mm screen and high specification presents the capability to make simple comparative non-contact measurement through to complex programmed measuring sequences with SPC capability and automatic edge detection. The horizontal light beam configuration is ideally suited to large machined or turned workpieces for mounting in vee blocks and centres. Features • 24"/600mm screen with 90º cross lines and chart clips • Heavy duty workstage with 18"/450mm x 8"/200mm measuring range and 2 machine slots for workpiece holders • Angular rotation of ± 15º on workstage for measuring threadforms or cutting tools • Vertical 8"/200mm Y axis power driven with joystick control • Lens magnification choice - 5x (single lens mount), 10x, 20x, 25x, 50x, 100x • 4 position rotating lens turret for ease of lens changing (excluding 5x) • Profile illumination with halog
